Greetings
- If you have a Freeman Technology FT4, Schulze RST, Brookfield Engineering PFT, or an E&G Associates iShear (Peschl) tester you should be able to PREDICT flow behavior rather than RANK flowability; often when you use your tester to rank your materials, powders that were deemed to have good flowability often have flow problems when handled. I will show you how to use the test results to predict if a powder will flow reliably in existing equipment, modify the equipment, or design new equipment.
- The 9th edition of Perry's Handbook will be published soon, and I am excited to be the author of the subsection on powder flow and hopper design.
- I have a doctorate in chemical engineering from the University of Colorado, but I like to say that I received a Ph.D. in process development from Cabot Corporation and a Ph.D. in bulk solids handling from Jenike & Johanson, Inc.
- My approach to consulting is to teach clients the fundamentals of bulk solids storage and handling so that they can measure powder flow properties, design bulk solids handling equipment, and solve powder handling problems by themselves.
Services
Consulting
- Process development
- Functional design recommendations
- Solutions to powder flow problems
Process Vessels
Moving powder bed dryers and purge vessels
Moving bed heat exchangers
Moving bed reactors
Contact
Quotations and Proposals
Please reach out at your convenience so we can discuss your project.
Send Message
Videos
When fine powders are handled, the desired discharge solids discharge sometimes cannot be reached due to vacuum that naturally develops near the hopper outlet. This results in counter flow of air into the hopper outlet, which can hinder flow. By properly adding a small amount air into the hopper, the adverse gas pressure gradient is removed, and the solids discharge rate is dramatically increased.
If you have a shear cell tester, instead of finding a powder's FFC value, you should use the test results to determine the size of a hopper outlet required to prevent obstructions to flow and the recommended mass flow hopper angle. This video provides a step-by-step procedure for using Jenike's method to design a mass flow hopper.
Favorite Places (I am not a rep, but these places are good!)
Gamlen Instruments
Powder Compaction Analysis
Rocky DEM
Discrete Element Method Software
Young Industries
Materials Handling Equipment
Solids Handling Technologies
Powder Flow Testing
IFPRI
Institute for Briquetting and Agglomeration
SciMed
Schulze Ring Shear Testers
Aveka
FEECO International
Wet Agglomeration Equipment
Downloads
- My Hopper Design Cliff Notes provide a nice summary of flow property test methods and bin design. When I give workshops, I provide these notes along with a spreadsheet that performs the calculations.
- Caking and its Prevention is the non-copyright version of an article that I wrote for Chemical Engineering magazine.
- Optimization of Pharmaceutical Formulations for Flow shows how Jenike's flowability coefficient FFC can be misinterpreted. It's better to measure the flow properties of a powder over a range of consolidation pressures so that critical hopper outlet dimensions and hopper angles can be calculated.
- I periodically add other documents on powder handling and processing. Be sure to visit and check for updates.
Hopper Design Cliff Notes (pdf)
DownloadCaking and Its Prevention (pdf)
DownloadOptimization of Pharmaceutical Formulations for Flow (pdf)
DownloadMoving Bed Process Vessels (pdf)
DownloadWet Granulation of Fumed Silica (pdf)
DownloadChoosing Agglomeration Processes (pdf)
DownloadCV (pdf)
DownloadPerry's Handbook Bulk Solids Testing and Hopper and Chute Design (pdf)
DownloadURI Notes (Password Required) (docx)
DownloadSt. Baldrick's Foundation
A good friend of mine is fighting cancer, and her daughter is shaving her head to raise money for cancer research. Please consider donating.
